Astrapi i Rack Mount Battery Module

Astrapi i Rack Mount Battery Module

The Tesla™ Astrapi i Rack Mount Battery Module provides an efficient source of clean backup power for industrial control and communication equipment. Depending on the model, the Battery Module uses four or eight lead acid dry cell batteries to provide reliable dc power that will run, protect, and ultimately extend the life of equipment when power is lost. As always, the unit is backed by a Tesla™ 2-year warranty, a trained support team, and an experienced staff of customer service professionals.


Astrapi i Rack Mount Battery Module Specifications

Dimensions: 28.98” L x 19” W x 5.19” H
736.2 mm x 482.6 mm x 131.9 mm
Weight: 99.5 lbs (45.13 kg) with 4 batteries
186 lbs (84.59 kg) with 8 batteries
Warranty:
  • 2 Years (3 Year Optional)

Models

Batteries:
12 Volt
24 Volt
48 Volt
4 Batteries
AST400-12
AST400-24
AST400-48
8 Batteries
AST800-12
AST800-24
AST800-48

Features

  • Maintenance-free design.
  • Dry Cell Batteries are not prone to Memory Effect.
  • DC output capable of delivering up to 48 Volts at 46 amp hours (depending on model).
  • Communications interface to connect with other Tesla™ Astrapi i Modules.
  • Exceeds MIL-STD-810/MIL-STD-461.
  • Fits in 3U rack space.
  • Conforms to EIA-310 standard.
  • Load shedding ability.
